Features:
◆Adopting imported linear rectangular guide rail, large loading , high accuracy, moves smoothly;
◆The perfect automatic oiling system, saves maintenance time and greatly extends the lifetime of the rail and machine ;
◆Z-axis with high-precision pre-tightening imported anti-backlash rolling ball screw to ensure the positioning accuracy of carving relief more accurate;
◆CNC control system with memory function, can continue to work after breaking of tools or power off;
◆ Gantry movement, the overall structure of the body, durable and non- deformation;
◆Multiple spindles can process at the same time, also can process independently, gaining more multiples of the processing efficiency than a single spindle engraver;
◆This series of machine with high hardness rack for transmission, fast, powerful, high cost/performance ratio;
◆National patent box-type column;
◆Software compatible:Compatible with any other advanced software of CAM in the world: Type3/Artcam/Castmate/Wentai/Pro-E/CAXA/Artcut/UG/JD/ and etc.
|
| |
ZMD-1325C/1625C
Kaxing
ZMD-1325C/1625C
ZMD-1325C/1625C
Features:
◆Adopting imported linear rectangular guide rail, large loading , high accuracy, moves smoothly;
◆The perfect automatic oiling system, saves maintenance time and greatly extends the lifetime of the rail and machine ;
◆Z-axis with high-precision pre-tightening imported anti-backlash rolling ball screw to ensure the positioning accuracy of carving relief more accurate;
◆CNC control system with memory function, can continue to work after breaking of tools or power off;
◆ Gantry movement, the overall structure of the body, durable and non- deformation;
◆Multiple spindles can process at the same time, also can process independently, gaining more multiples of the processing efficiency than a single spindle engraver;
◆This series of machine with high hardness rack for transmission, fast, powerful, high cost/performance ratio;
◆National patent box-type column;
◆Software compatible:Compatible with any other advanced software of CAM in the world: Type3/Artcam/Castmate/Wentai/Pro-E/CAXA/Artcut/UG/JD/ and etc.
| 产品型号Model | ZMD-1325C | ZMD-1625C |
| 平台尺寸 Table | 1300*2500mm | 1600*2500mm |
| 进料高度 Feed height | 200mm | 300mm |
| 最大空行速度 Max. ldle speed | 20m/min | |
| 最大工作速度 Max. working speed | 10m/min | |
| 主轴功率 Spindle power | 800W-2.2KW变频水冷主轴 800W-2.2KW Variable frequen water cooled spindle | |
| 主轴转速 Spindle speed | 6000~24000RPM | |
| 工作电压 Working voltage | AC220V/50Hz或AC380/50Hz | |
| 雕刻刀具 Tool | φ3.175/4/6/12.7mm | |
| 文件格式 File format | G代码/HPGL G code/HPGH | |
| 定位精度 Positioning accuracy | ±0.1mm | |
| 重复定位精度 Repeatability positioning accuracy | ±0.05mm | |
| 控制系统 Control system | 维宏系统 Nc studio | |
Mahogany antique furniture, white wood European furniture, antique furniture, hollow screen, solid wood door, craft wooden door, paint-free door, cabinet door, craft fan window, various tables, sofa, solid wood furniture, panel furniture, wave board, decoration , computer tables, mahjong tables, office furniture, musical instruments, wooden speakers, sewing machines, electrical cabinet panels, sports equipment advertising signs, logo production, acrylic cutting, plastic light boxes, curtain wall production, aluminum and other processing, copper, composited sheet and other non-ferrous metal mold processing, etc.
Features:
◆Adopting imported linear rectangular guide rail, large loading , high accuracy, moves smoothly;
◆The perfect automatic oiling system, saves maintenance time and greatly extends the lifetime of the rail and machine ;
◆Z-axis with high-precision pre-tightening imported anti-backlash rolling ball screw to ensure the positioning accuracy of carving relief more accurate;
◆CNC control system with memory function, can continue to work after breaking of tools or power off;
◆ Gantry movement, the overall structure of the body, durable and non- deformation;
◆Multiple spindles can process at the same time, also can process independently, gaining more multiples of the processing efficiency than a single spindle engraver;
◆This series of machine with high hardness rack for transmission, fast, powerful, high cost/performance ratio;
◆National patent box-type column;
◆Software compatible:Compatible with any other advanced software of CAM in the world: Type3/Artcam/Castmate/Wentai/Pro-E/CAXA/Artcut/UG/JD/ and etc.
| 产品型号Model | ZMD-1325C | ZMD-1625C |
| 平台尺寸 Table | 1300*2500mm | 1600*2500mm |
| 进料高度 Feed height | 200mm | 300mm |
| 最大空行速度 Max. ldle speed | 20m/min | |
| 最大工作速度 Max. working speed | 10m/min | |
| 主轴功率 Spindle power | 800W-2.2KW变频水冷主轴 800W-2.2KW Variable frequen water cooled spindle | |
| 主轴转速 Spindle speed | 6000~24000RPM | |
| 工作电压 Working voltage | AC220V/50Hz或AC380/50Hz | |
| 雕刻刀具 Tool | φ3.175/4/6/12.7mm | |
| 文件格式 File format | G代码/HPGL G code/HPGH | |
| 定位精度 Positioning accuracy | ±0.1mm | |
| 重复定位精度 Repeatability positioning accuracy | ±0.05mm | |
| 控制系统 Control system | 维宏系统 Nc studio | |
Mahogany antique furniture, white wood European furniture, antique furniture, hollow screen, solid wood door, craft wooden door, paint-free door, cabinet door, craft fan window, various tables, sofa, solid wood furniture, panel furniture, wave board, decoration , computer tables, mahjong tables, office furniture, musical instruments, wooden speakers, sewing machines, electrical cabinet panels, sports equipment advertising signs, logo production, acrylic cutting, plastic light boxes, curtain wall production, aluminum and other processing, copper, composited sheet and other non-ferrous metal mold processing, etc.
