Cylinder Engraving Machine Series(RD-20100-6)

Features:

Adopting imported rolling ball screw ,and high precision rotary axis,with the ability to handle different size of cylinder -work pieces;

National patent box-type column;

High precision drive system;

Employing unique intellective prediction arithmetic fully develop the proficiency of driving system,which achieves the high speed processing, synchronization of line and curve processing as well as smooth curve;

CNC control system with memory function, can continue to work after breaking of tools or power off;

Software compatible:Compatible with any other advanced software of CAM in the world: Type3/Artcam/Castmate/Wentai/Pro-E/CAXA/Artcut/UG/JD/ and etc.

Availability:

  • RD-20100-6

  • Kaxing

  • RD-20100-6

  • RD-20100-6

Product Description

Features:

Adopting imported rolling ball screw ,and high precision rotary axis,with the ability to handle different size of cylinder -work pieces;

National patent box-type column;

High precision drive system;

Employing unique intellective prediction arithmetic fully develop the proficiency of driving system,which achieves the high speed processing, synchronization of line and curve processing as well as smooth curve;

CNC control system with memory function, can continue to work after breaking of tools or power off;

Software compatible:Compatible with any other advanced software of CAM in the world: Type3/Artcam/Castmate/Wentai/Pro-E/CAXA/Artcut/UG/JD/ and etc.

taoci-yuanzhudiaokejixilieRD
Product Paramenters
产品型号 Model RD-20100-6
加工长度 Working length 1000m
加工直径 Working diameter ≤285mm
最大空行速度 Max. ldle speed 15m/min
最大工作速度 Max. working speed 10m/min
主轴功率 Spindle power 1.5KW~2.2KW变频水冷主轴 1.5KW~2.2KW Variable frequen water cooled spindle
加工模式 Processing mode 圆雕 cylinde
主轴转速 Spindle speed 6000~24000RPM
工作电压 Working voltage AC220V/50Hz
雕刻刀具 Tool φ3.175/4/6mm
文件格式 File format G代码/HPGL G code/HPGH
定位精度 Positioning accuracy ±0.1mm
重复定位精度 Repeatability positioning accuracy ±0.05mm
控制系统 Control system 维宏系统 Nc studio
Application

European-style marble pillar, antique mahogany furniture,drum stool,brush pencil vase, brush , chopsticks,bamboo handicrafts,dimensional handicrafts,jewelry,any cylindrical objects etc.
