Screw Engraving Machine (Neptune First Generation Of B Series)

Features:

Imported high precision rolling ball screw drive, high accuracy and high speed;

Constant power, water cooling, frequency conversion spindle, good performance,large torque,high efficiency;

Control system adjusts the speed of processing , idle speed and cutting speed, increases the processing efficiency and yield, extends the lifetime of tools;

CNC control system with memory function, can continue to work after breaking of tools or power off;

Software compatible:Compatible with any other advanced software of CAM in the world: Type3/Artcam/Castmate/Wentai/Pro-E/CAXA/Artcut/UG/JD/ and etc.

Availability:

  • JK-1080/8090/6590B/1325B

  • Kaxing

  • JK-1080/8090/6590B/1325B

  • JK-1080/8090/6590B/1325B

Product Description

Features:

Imported high precision rolling ball screw drive, high accuracy and high speed;

Constant power, water cooling, frequency conversion spindle, good performance,large torque,high efficiency;

Control system adjusts the speed of processing , idle speed and cutting speed, increases the processing efficiency and yield, extends the lifetime of tools;

CNC control system with memory function, can continue to work after breaking of tools or power off;

Software compatible:Compatible with any other advanced software of CAM in the world: Type3/Artcam/Castmate/Wentai/Pro-E/CAXA/Artcut/UG/JD/ and etc.

quansigangdiaokejiJK-1325B
Product Paramenters


产品型号Model JK-1080 JK-8090 JK-6590B JK-1325B
平台尺寸 Table 1000*800mm 800*900mm 650*900mm 1300*2500mm
进料高度 Feed height 120mm 160mm
最大空行速度 Max. ldle speed 15m/min
最大工作速度 Max. working speed 10m/min
主轴功率 Spindle power 800W-2.2KW国产品牌水冷主轴 Domestic brand water cooled spindle 800W-3.0KW变频水冷主轴  Variable frequen water cooled spindle
主轴转速 Spindle speed 6000~24000RPM
工作电压 Working voltage AC220V/50Hz或AC380/50Hz
雕刻刀具 Tool φ3.175/4/6/12.7mm
文件格式 File format G代码/HPGL G code/HPGH
定位精度 Positioning accuracy ±0.03mm
重复定位精度 Repeatability positioning accuracy ±0.02mm
控制系统 Control system 维宏系统 Nc studio
Application

Classical mahogany furniture, antique furniture, cabinet doors, table tennis racket, shrines, box, bamboo handicrafts, photo frames, craft gifts, toys gifts, building models, decorative and decorating industry, advertising signs, signs, crystal word production, electrical equipment panel, moon cake mold processing etc.
