Wooden Engraving Machine A Series(ZMD-1313A/1325A/1620A/1625A)

Features:

It is able to add pressure roller device, which is simple and convenient for fixing;

Adopting imported linear guide rail, large loading ,running smoothly, high accuracy;

X / Y axis with rack transmission,Z axis with screw drive , high precision, high wear resistance;

The perfect automatic oiling system, saves maintenance time and greatly extends the lifetime  of the rail ;

Adopting domestic famous constant power water-cooled frequency conversion spindle and high-performance inverter, perfect performance, large torque, high efficiency;

 Adopting professional drivers and motors, Y-axis with dual motor drive, faster, more stable;

Software compatible: Compatible with any other advanced software of CAM in the world: Type3/Artcam/Castmate/Wentai/Pro-E/CAXA/Artcut/UG/JD/ and etc.

Availability:

  • ZMD-1313A/1325A/1620A/1625A

  • Kaxing

  • ZMD-1313A/1325A/1620A/1625A

  • ZMD-1313A/1325A/1620A/1625A

Product Description

Features:

It is able to add pressure roller device, which is simple and convenient for fixing;

Adopting imported linear guide rail, large loading ,running smoothly, high accuracy;

X / Y axis with rack transmission,Z axis with screw drive , high precision, high wear resistance;

The perfect automatic oiling system, saves maintenance time and greatly extends the lifetime  of the rail ;

Adopting domestic famous constant power water-cooled frequency conversion spindle and high-performance inverter, perfect performance, large torque, high efficiency;

 Adopting professional drivers and motors, Y-axis with dual motor drive, faster, more stable;

Software compatible: Compatible with any other advanced software of CAM in the world: Type3/Artcam/Castmate/Wentai/Pro-E/CAXA/Artcut/UG/JD/ and etc.

mugongdiaokeji-Axilie-ZMD-1325A

Product Paramenters


产品型号Model ZMD-1313A ZMD-1325A ZMD-1620A ZMD-1625A
平台尺寸 Table 1300mm*1300mm 1300mm*2500mm 1600mm*2000mm 1600mm*2500mm
进料高度 Feed height 180mm/230mm/280mm
最大空行速度 Max. ldle speed 20m/min
最大工作速度 Max. working speed 10m/min
主轴功率 Spindle power 800W-5.5KW变频水冷主轴 800W-5.5KW Variable frequen water cooled spindle
主轴转速 Spindle speed 6000~24000RPM
工作电压 Working voltage AC220V/50Hz或AC380/50Hz
雕刻刀具 Tool φ3.175/4/6/12.7mm
文件格式 File format G代码/HPGL G code/HPGH
定位精度 Positioning accuracy ±0.1mm
重复定位精度 Repeatability positioning accuracy ±0.05mm
控制系统 Control system 维宏系统 Nc studio
Application

Mahogany antique furniture, white wood European furniture, antique furniture, screen hollow, solid wooden doors, paint-free doors, cabinet doors, craft fan windows, all kinds of tables, sofas, panel furniture, advertising signs, logo production, acrylic cutting , plastic light boxes, curtain wall production, aluminum and other processing, copper, composited sheet and other non-ferrous metal mold processing.

A-jpg
