Three-dimensional Engraving Machine

Feature: ◆Stable structure: the machine is fully cast, processed by five-sided gantry milling machine, the machine tool is more precise and more stable; tempering and aging treatment, firm and not deformed; ◆Excellent components: NC studio control system ,adopts Taiwan linear guide , three-axis ball screw, which has large bearing capacity and accurate lowering of the knife. ◆Adopt easy servo drive system, large torque and complete safety system ◆Rotary axis by reducer drive, running more smoothly ◆Four spindles at the same time, four axes and four linkages, high processing efficiency
Availability:

  • RD-1505B/1805/6060B-8

  • Kaxing

  • RD-1505B/1805/6060B-8

  • RD-1505B/1805/6060B-8

Product Description

 Feature:

◆Stable structure: the machine is fully cast, processed by five-sided gantry milling machine, the machine tool is more precise and more stable; tempering and aging treatment, firm and not deformed;

◆Excellent components: NC studio control system ,adopts Taiwan linear guide , three-axis ball screw, which has large bearing capacity and accurate lowering of the knife.

◆Adopt easy servo drive system, large torque and complete safety system

◆Rotary axis by reducer drive, running more smoothly

◆Four spindles at the same time, four axes and four linkages, high processing efficiency

RD-1505B RD-1606B RD-1805_2918_2918
Product Paramenters


XYZ行程 XYZ stroke X300mm/Y500mm/Z150mm X700mm/Y600mm/Z180mm X400mm/Y400mm/Z180mm
旋转轴直径 Rotary Dia ≤150mm ≤160mm ≤140mm
旋转轴长度 Rotary length 500mm 600mm 400mm
定位精度 Positioning accuracy ±0.05mm
重复定位精度 Repeatability positioning accuracy ±0.02mm
台面结构 Table strucure 龙门移动 Gantry mobile 平台移动 Moveable table
XYZ项传动结构 XYZ Transmission strucure 丝杆 Screw ball
最大空行速度 Max. ldle speed 15000mm/min
最大工作速度 Max. working speed X/Y:10000mm/min;Z:3000mm/min
主轴功率 Spindle power 800W~1.5KW国产水冷 Domestic water cooled 800W~1.5KW
主轴转速 Spindle speed 6000~24000RPM
运行模式 Driving system 国产混合伺服(可选交流伺服)Domestic hybrid servo(optional AC servo)
工作电压 Working voltage AC220V/50Hz
运行指令 File format G代码/NC代码/ENG代码  G/NC/ENG code
控制系统 Control system 四轴控制系统 Four-axis control system
Application

◆such as three-dimensional processing;

◆360-degree sculpture of human body, Buddha, arts and crafts, furniture, etc

◆Processing materials: solid wood, bamboo, acrylic and so on
