Feature:
◆Machine instead of labors: One machine can replace the ordinary three procedures, such as scribing operator, cnc operator, polishing operator. Greatly save labor costs and preventing big harmful to workers by ordinary processing, bring a revolutionary safe processing environment to factories and workers but greatly increase product benefits .
◆Solved too much materials wast in soid wood processing, other company devices control wast in 12cm but ours control around 6cm, greatly saving materials cost.
◆High production, processing speed can reach to 4m/min.
◆Training advantages: The company improves a complete set of training programs, including drawing training and machine operating training, so that customers buy equipment without after-sales concerns
◆Tool advantages: The company provides full set of tools for customers to save tool costs. One tool can be used for 3 days, which greatly helps customers to save the cost of tool.
Availability: | |
---|---|
| |
Feature:
◆Machine instead of labors: One machine can replace the ordinary three procedures, such as scribing operator, cnc operator, polishing operator. Greatly save labor costs and preventing big harmful to workers by ordinary processing, bring a revolutionary safe processing environment to factories and workers but greatly increase product benefits .
◆Solved too much materials wast in soid wood processing, other company devices control wast in 12cm but ours control around 6cm, greatly saving materials cost.
◆High production, processing speed can reach to 4m/min.
◆Training advantages: The company improves a complete set of training programs, including drawing training and machine operating training, so that customers buy equipment without after-sales concerns
◆Tool advantages: The company provides full set of tools for customers to save tool costs. One tool can be used for 3 days, which greatly helps customers to save the cost of tool.
产品型号Model | SQ-1815 | SQ-2015 | SQ-2415 |
行程 Work stroke | X1800mm Y1500mm Z200mm | X2000mm Y1500mm Z200mm | X2400mm Y1500mm Z200mm |
定位精度 Positioning accuracy | ±0.1mm | ||
重复定位精度 Repeatability positioning accuracy | ±0.05mm | ||
结构 Transmission | XY轴丝杆传动,V轴齿条传动 XY axis screw transmission,V axis rack transmission | ||
最大空行速度 Max. ldle speed | 10000mm/min | ||
最大工作速度 Max. working speed | X/Y:4000mm/min;V:400mm/min | ||
主轴电机功率 Spindle power | 9KW国产风冷主轴HQD 9.0KW air cooled spindle | ||
主轴电机转速 Spindle speed | 0~18000RPM | ||
运行指令 File format | DXF 文件格式 DXF file | ||
操作系统 Control system | 定制控制系统 Customized control system | ||
工作电压 Working voltage | AC380V/50Hz |
Mainly used for furniture enterprises to process soid wood : such as bed backrest, sofa backrest, chair backrest, and other solid wood cutting and processing requirements.
Feature:
◆Machine instead of labors: One machine can replace the ordinary three procedures, such as scribing operator, cnc operator, polishing operator. Greatly save labor costs and preventing big harmful to workers by ordinary processing, bring a revolutionary safe processing environment to factories and workers but greatly increase product benefits .
◆Solved too much materials wast in soid wood processing, other company devices control wast in 12cm but ours control around 6cm, greatly saving materials cost.
◆High production, processing speed can reach to 4m/min.
◆Training advantages: The company improves a complete set of training programs, including drawing training and machine operating training, so that customers buy equipment without after-sales concerns
◆Tool advantages: The company provides full set of tools for customers to save tool costs. One tool can be used for 3 days, which greatly helps customers to save the cost of tool.
产品型号Model | SQ-1815 | SQ-2015 | SQ-2415 |
行程 Work stroke | X1800mm Y1500mm Z200mm | X2000mm Y1500mm Z200mm | X2400mm Y1500mm Z200mm |
定位精度 Positioning accuracy | ±0.1mm | ||
重复定位精度 Repeatability positioning accuracy | ±0.05mm | ||
结构 Transmission | XY轴丝杆传动,V轴齿条传动 XY axis screw transmission,V axis rack transmission | ||
最大空行速度 Max. ldle speed | 10000mm/min | ||
最大工作速度 Max. working speed | X/Y:4000mm/min;V:400mm/min | ||
主轴电机功率 Spindle power | 9KW国产风冷主轴HQD 9.0KW air cooled spindle | ||
主轴电机转速 Spindle speed | 0~18000RPM | ||
运行指令 File format | DXF 文件格式 DXF file | ||
操作系统 Control system | 定制控制系统 Customized control system | ||
工作电压 Working voltage | AC380V/50Hz |
Mainly used for furniture enterprises to process soid wood : such as bed backrest, sofa backrest, chair backrest, and other solid wood cutting and processing requirements.
