hw04
Features:
◆Aging treatment on the bed, strong and not deformed, durable;
◆ Using imported high-precision ball screw transmission, high accuracy and fast speed;
◆ Adopt constant power water-cooled frequency conversion spindle, with good performance, large torque and high efficiency;
◆ The system intelligently controls the processing speed, idling speed and cutting speed to improve processing efficiency, extend tool life and increase yield;
◆ Breakpoint memory is adopted to ensure that processing can be continued in the event of an accident (knife break, power failure) or the next day;
◆ Compatible with any advanced CAM software in the world:Type3 /Artcam/ CAXA / UG / Pro-E /Mastercam/ JD /Wentai et al.
Technical Parameters:
| Product number | JK-1313B second generation | |
| Platform size | 1300 × 1300mm | |
| Feed height | 180mm | |
| Idling speed | 15m / min | |
| Processing speed | 10m / min | |
| Spindle power | 800W ～ 3.0KW frequency conversion water-cooled motor | |
| Spindle speed | 6000~24000 rpm / min | |
| Operating Voltage | AC220V / 50Hz or AC380V / 50Hz | |
| Carving tool | ￠ 3.175 / 4/6 / 12.7mm | |
| file format | G code / HPGL | |
| positioning accuracy | ± 0.03mm | |
| Repeatability | ± 0.02mm | |
| Control System | Nc studio system | |
Scope of application:
Classical mahogany furniture, European-style furniture, antique vintage furniture, cabinet doors, table tennis rackets, Buddhist altars, birthday boxes, bamboo and wooden crafts, photo frames, craft gifts, toy gifts, architectural models, decoration industry, advertising signs, signs, crystal characters, Blister light boxes, electrical equipment panels, moon cake molds and other processing.
