yzdk04
Features:
◆ Use imported ball screw, high precision indexing head, large clamping diameter, can adapt to different specifications of cylindrical materials;
◆ National patent box column;
◆ High-precision drive system;
◆Adopt unique intelligent prediction algorithm to give full play to the driving potential to achieve high-speed machining, curved straight lines, and smoother curves;
◆Using breakpoint memory to ensure that processing can be continued in the event of an accident (knife break, power failure) or the next day;
◆Strong compatibility, compatibleType3 /Artcam/ CAXA / UG / Pro-E /Mastercam/Wentai et al.
Technical Parameters:
| Product number | RD-3010 |
| Processing length | 1000mm |
| Chuck specifications | ≤300mm |
| Idling speed | 15m / min |
| Processing speed | 10m / min |
| Spindle power | 800w~2.2KW frequency conversion water-cooled spindle |
| Processing mode | Round carving / flat round two carvings |
| Spindle speed | 6000~24000 rpm / min |
| Operating Voltage | AC220V / 50Hz |
| Carving tool | ￠ 3.175 / 4 / 6mm |
| file format | G code / HPGL |
| positioning accuracy | ± 0.03mm |
| Repeatability | ± 0.02mm |
| Control System | Nc studio system |
Scope of application:
European-style Roman columns, antique mahogany furniture, drum stools, pen holders, writing brushes, chopsticks, moso bamboo crafts, three-dimensional crafts, jewelry gift pendants, various cylindrical product processing.
Features:
◆ Use imported ball screw, high precision indexing head, large clamping diameter, can adapt to different specifications of cylindrical materials;
◆ National patent box column;
◆ High-precision drive system;
◆Adopt unique intelligent prediction algorithm to give full play to the driving potential to achieve high-speed machining, curved straight lines, and smoother curves;
◆Using breakpoint memory to ensure that processing can be continued in the event of an accident (knife break, power failure) or the next day;
◆Strong compatibility, compatibleType3 /Artcam/ CAXA / UG / Pro-E /Mastercam/Wentai et al.
Technical Parameters:
| Product number | RD-3010 |
| Processing length | 1000mm |
| Chuck specifications | ≤300mm |
| Idling speed | 15m / min |
| Processing speed | 10m / min |
| Spindle power | 800w~2.2KW frequency conversion water-cooled spindle |
| Processing mode | Round carving / flat round two carvings |
| Spindle speed | 6000~24000 rpm / min |
| Operating Voltage | AC220V / 50Hz |
| Carving tool | ￠ 3.175 / 4 / 6mm |
| file format | G code / HPGL |
| positioning accuracy | ± 0.03mm |
| Repeatability | ± 0.02mm |
| Control System | Nc studio system |
Scope of application:
European-style Roman columns, antique mahogany furniture, drum stools, pen holders, writing brushes, chopsticks, moso bamboo crafts, three-dimensional crafts, jewelry gift pendants, various cylindrical product processing.
