Features:
◆ Use imported ball screw, high precision indexing head, large clamping diameter, can adapt to different specifications of cylindrical materials;
◆ National patent box column;
◆ High-precision drive system;
◆Adopt unique intelligent prediction algorithm to give full play to the driving potential to achieve high-speed machining, curved straight lines, and smoother curves;
◆Using breakpoint memory to ensure that processing can be continued in the event of an accident (knife break, power failure) or the next day;
◆Strong compatibility, compatibleType3 /Artcam/ CAXA / UG / Pro-E /Mastercam/Wentai et al.
Technical Parameters:
Product number | RD-6590 |
Processing length | 300mm |
Chuck specifications | ≤100mm |
Idling speed | 15m / min |
Processing speed | 10m / min |
Spindle power | 800w~2.2KW frequency conversion water-cooled spindle |
Processing mode | Round carving / flat round two carvings |
Spindle speed | 6000~24000 rpm / min |
Operating Voltage | AC220V / 50Hz |
Carving tool | ¢ 3.175 / 4 / 6mm |
file format | G code / HPGL |
positioning accuracy | ± 0.03mm |
Repeatability | ± 0.02mm |
Control System | Nc studio system |
Scope of application:
European-style Roman columns, antique mahogany furniture, drum stools, pen holders, writing brushes, chopsticks, moso bamboo crafts, three-dimensional crafts, jewelry gift pendants, various cylindrical product processing.
